A talk by Yuchen Fama and Ashish Kamra (Red Hat) on inference serving optimization on Kubernetes, presented via the llm-d project. It covers two main levers: KV cache-aware routing (illustrated by a live demo where cache hits cut request latency from ~3s to ~1s, motivated by real agentic traces with 90%+ cache hit rates and high input/output token ratios) and prefill/decode (P/D) disaggregation, which separates compute-bound prefill from memory-bound decode — reported to reduce P99 inter-token latency from ~900ms to ~100ms across 16 H100s serving gpt-oss. The talk also discusses when disaggregation wins (mid-concurrency bands, requiring RDMA/RoCE fabric) versus staying aggregated, and closes with a case study of GLM 5.2 on H200s at a 3:1 prefill-to-decode ratio, reported at 4x faster time to first token and 60% more requests. These performance figures are as stated by the speakers. # Video Identity Extraction: KV Cache-Aware Routing and P/D Disaggregation on Kubernetes ## Presentation Context - **Format**: Conference talk ("welcome everyone to yet another inference talk... I hope you have had a good conference so far"), timed at roughly 20 minutes ("the agenda for the next 20 minutes or so"). - **Speakers**: Two Red Hat employees — Ashish Kamra, self-described "senior manager of performance engineering at Red Hat," and Yuchen, self-described "product manager at Red Hat Inference working closely with vLLM and AMD core maintainers, also a contributor myself." ## Explicit Self-Description (Creator Claims) - **Red Hat positioning beyond Linux/Kubernetes**: "since Red Hat is better known as the Linux company for enterprise Linux and uh the Kubernetes company for OpenShift uh but more recently we are also a major player in open source AI inference with us being the top contributor in vLLM, llm-d and the [K]Serve projects." - **Claimed project incubation**: "having incubated GuideLLM for benchmarking LLM, LLM Compressor for model quantization, and speculators for speculative decoding models," plus "an optimized model hub on Hugging Face under the Red Hat AI [brand]." - **Forward-looking platform claim**: "we are also building the platform for the next wave of agentic inference workloads." - **Open-ecosystem stance**: "distributed inference is not [a] challenge... a single company can solve alone. We're proud to be building this future in the open alongside our incredible ecosystem collaborators — CoreWeave, Google, IBM, NVIDIA..." ## Observable Presentation Evidence ### Intended Audience - **Practitioners deploying LLM inference at scale** — technical depth on tensor parallelism, RDMA/RoCE fabrics, P99 ITL, and capacity planning implies an infrastructure/platform engineering audience. - **Conference-attending inference specialists** — references to "earlier sessions" (inference perf talks, Anthropic API pricing discussion) and "I'm sure you people who have been in the room must have heard these terms many times by now." - **Prospective contributors/customers** — explicit invites: "join the SIG group and contribute," "We do have a booth downstairs. Feel free to stop by, ask us any questions." - **Customer-representative framing**: "when we talk to our customers and they usually don't have the luxury of B200. They have a lot of H200." ### Claimed Scope of Content - Deep-dive on **KV cache-aware routing** and **prefill/decode (P/D) disaggregation** in llm-d on Kubernetes, for agentic workloads. - Includes a **live demo** (KV cache hit across turns), **benchmark results** (GPT-OSS 12B on 16/64 H100s), and an **ongoing case study** serving "GLM 5.2" on H200 clusters ("still ongoing as we speak"). - References to supporting material: "a free course on deeplearning.ai by Cedric and with Andrew Ng" and "a series of blogs on the Red Hat developer portal on distributed inference." ### Demonstrated Communication Patterns - **Evidence-led argumentation**: benchmark caveats ("public inference benchmark results... very steady state, isolated, highly sanitized numbers") contrasted with "the chaotic reality of multi-turn interactions." - **Balanced framing**: explicitly resists hype — "I don't want to leave you [thinking] that PD is the answer to everything and it's a magic bullet," followed by a decision matrix of when P/D is and isn't appropriate. - **Concrete quantified claims**: "P99 ITL hovers roughly around 900 milliseconds" vs. "almost nine times better at 100 milliseconds" in disaggregated mode; "cache hit rate oftentimes well exceeding 90%"; "10x cost difference between cached and non-cached tokens." - **Transcript-level anomalies worth noting**: several apparent transcription errors ("GLM 5.2," "B B B... BF6," "sub Asian panel," "3 seconds" demo timings) — these are as-transcribed and cannot be verified against the audio. ## Summary of Identity Signals | Dimension | Evidence | |---|---| | **Who presents** | Two named Red Hat employees (performance engineering manager + product manager) | | **Audience** | Conference-attending inference/infrastructure practitioners and potential contributors/customers | | **Scope claimed** | Red Hat as top contributor to vLLM/llm-d/KServe, incubator of GuideLLM/LLM Compressor, builder of agentic inference platform | | **Demonstrated pattern** | Technical deep-dives with demos, benchmarks, and decision frameworks rather than pure marketing | # Delivery Observations — KV Cache-Aware Routing and P/D Disaggregation (Yuchen Fama & Ashish Kamra) ## Overall Format - **Two-presenter talk** with explicit handoffs. Ashish opens and closes the framing sections; Yuchen covers workload analysis, KV cache, and the case study; Ashish covers LLMD mechanics, PD disaggregation, and results. - Handoffs are verbal and explicit: *"I will hand over to you to uh walk you through more of it"* and later *"I think with these uh I will hand it over to Euchen to anchor some of the concepts."* ## Verbal Fillers and Disfluencies - **Heavy use of "uh" and "um"** by both speakers throughout — this is the most pervasive delivery feature, e.g., *"Um, welcome everyone to yet another inference talk"* and *"So, so how does PD actually work in practice in LMD? So, LNMD uses um uh you know like okay, we'll start with step one."* - **Repeated word-level restarts and self-corrections**, e.g., *"we we you you look at public inference"*, *"and also you know when you when you"*, *"your lat uh your your throughput"*, *"highly multi multi-node model execution."* ## Recurring Phrases - **"Agentic workloads / agentic era"** — used repeatedly as the framing term, from the opening ("challenges of LLM deployments for agentic workloads") through the close ("the fundamental shift for agentic workload"). - **"You heard from earlier sessions"** — a recurring callback pattern referencing other conference talks (at least three instances). - **"Next slide" / "so next"** as transition markers. - Ashish's repeated pre-emptive framing: *"you must have heard from some of the previous talks as well."* ## Teaching Habits - **Rhetorical question → answer structure**: *"but before that what does problem does it solve? So often times the prefix routing KV cache routing helps you solve the TTFT problem... how do we solve that? So prefill decode disaggregation is a really powerful technique."* - **Step-by-step walkthroughs** for mechanisms: *"okay, we'll start with step one. A incoming request hits the gateway router..."* - **Concrete numbers as evidence**: cache hit rates ("well exceeding 90%"), ratios ("over a 100 ratio"), latency figures ("roughly 900 milliseconds" vs "100 milliseconds"), hardware configs ("16 H100s", "TP4", "TP8"). - **Live demo narration**: Yuchen walks through a recorded demo turn-by-turn (*"So, okay. So, this is a example of a KV cache aware routing. As you see, when we send the very first request..."*). - **Honest qualification / caveat-giving**, especially Ashish: *"but I don't want to leave you guys that PD is the answer to everything and it's a magic bullet"* — followed by a decision matrix of when *not* to use PD. ## Vocabulary and Register - **Dense technical jargon used without simplification**: TTFT, ITL, ISL/OSL, TP/DP/EP, RDMA, P99, tensor parallelism — assumed audience familiarity. - **Colloquialisms mixed with jargon**: "pull the curtain back", "magic bullet", "wildl path" (unclear — possibly "well-trodden path"; transcript uncertainty), "our favorite open coding model". - **Qualifying adverbs**: "oftentimes", "roughly", "kind of", "you know" appear frequently, softening claims. ## Time and Pacing Awareness - Both speakers signal time pressure near the end: *"um I know we're running out of time really quick"* and the agenda framing "for the next 20 minutes or so". ## Uncertainty Notes - **Transcript garbling at [1182]** — the long "B B B B..." run before "BF16 KV cache" is likely a transcription artifact of "BF16"; the intended claim appears to be that BF16 KV cache outperformed FP8 for longer prefill, but exact wording is unverifiable. - **Speaker name inconsistency**: the transcript renders the co-presenter as "Yuch Chen", "Euchin", and "Euchen" — likely transcription variants of "Yuchen"; only the title spelling can be trusted. - **"GLM 5.2"** may be a transcription artifact; cannot verify the model name beyond the transcript. # Position Record: KV Cache-Aware Routing and P/D Disaggregation on Kubernetes **Video:** "KV Cache-Aware Routing and P/D Disaggregation on Kubernetes — Yuchen Fama & Ashish Kamra, Red Hat" ## Speakers - **Ashish Kamra** — Senior Manager of Performance Engineering, Red Hat (self-introduced) - **Yuchen (Yuch Chen)** — Product Manager, Red Hat Inference; contributor working with vLLM and AMD core maintainers (self-introduced) --- ## 1. Framing: Agentic Workloads Break Classic Inference Assumptions **Speaker: Yuchen** - Public inference benchmarks show **steady-state, sanitized numbers** that hide "the chaotic reality of multi-turn interactions, massive context fluctuations" typical of agentic workloads. - Characteristics observed in real workloads (e.g., SWE-bench, traces from real-world cloud coding sessions): - **Multi-turn is the new standard** — from a few turns up to **3,000 turns**. - Agents frequently reuse system prompts/tool definitions → **cache hit rates often exceed 90%**. - **Input/output ratios massive** — often over 100:1, sometimes higher. - **Context management is highly variable** — averages are insufficient; distributions and **P90 numbers** matter, especially for capacity planning. - Patterns like "sub-agent panels" further complicate scheduling. - To help study these patterns, Red Hat collaborated with **Google and IBM** on a **trace replay tool in Inference Perf**. - Optimization target shifts from raw throughput to **interactive latency** with client-driven context, since the client defines prompt structure. - Metrics must evolve: measure **cached throughput separately** — economic stakes are high; citing Anthropic API pricing, there is a **10x cost difference between cached and non-cached tokens**. ## 2. KV Cache-Aware Routing and Management (LLM-d) **Speaker: Yuchen** - LLM-d router has flexible **endpoint picker (EP) plugins** that route requests to pods satisfying **KV cache locality and load criteria**. - EP probes pods (e.g., vLLM pod metrics), scoring running/waiting requests, KV cache utilization, and prefix cache availability — scheduling to the pod with lowest load and highest cache-hit probability. - Cache management efforts for hot/warm/cold caches: - Additional **offloading tiers**: NVMe SSD, file system XFS. - **KV-centric stores** (e.g., Mooncake). - **Eviction policies**: priority and session pinning, to keep context where needed. **Demo (Yuchen):** - First request populates KV cache: ~3 seconds, no cache hit. - Second turn reuses cache (same system prompt): ~1 second, same pod address. - New system prompt: ~3 seconds, no hit, different pod. - Same system prompt, new user prompt: cache reused, ~1 second. - **Claimed benefit:** prefix routing solves **TTFT** and improves throughput; however, agentic workloads care about **inter-token latency (ITL)** too — motivating P/D disaggregation, which "there are times it doesn't work." ## 3. LLM-d Overview and P/D Disaggregation Mechanics **Speaker: Ashish** - LLM-d: high-performance, Kubernetes-native (now also non-Kubernetes) distributed LLM inference framework under **CNCF**; components: router/EP, workload APIs (LeaderWorkerSet, DisaggregatedSet), autoscalers that independently scale pods on capacity bounds and traffic mix. - **Why P/D exists:** in aggregated serving, one pod optimizes both TTFT and ITL. Colocating prefill and decode causes **phase interference**: - Prefill: high compute, bursty, high FLOPS, thrives on large batch parallelism. - Decode: memory-bandwidth hungry, latency sensitive, needs heavy cache residency. - A sudden long prefill stalls ongoing decode → jitter in streaming latency. - **Mechanics:** request hits gateway router → EP selects PD disaggregation and workers → router coordinates with prefill worker → prefill builds initial KV cache and outputs **KV transfer metadata** → decode worker pulls the KV caches over the network fabric using that metadata. ## 4. Experimental Results (Internal, Red Hat) **Speaker: Ashish** - **ITL experiment:** Aggregated: P99 ITL ~900ms with fluctuation; PD: ~100ms — "almost nine times better" and smoother. - Setup: GPT-OSS 12B, 16×H100; aggregated = 4 replicas TP4; PD = 2 prefill + 2 decode, TP4; multi-turn workload with 10,000-token prefix, 128 tokens per turn. - **Concurrency regime chart:** baseline = aggregated with default Kubernetes scheduling; middle = aggregated + KV-cache-aware routing (gains from routing alone); top = PD (2 prefill + 2 decode). - **PD shines in the middle concurrency regime**; similar to aggregated at low and high concurrency — "classic parita [Pareto] curves." - **Second setup:** GPT-OSS 12B, 64×H100; aggregated = 8 replicas TP8; PD = 3 prefill + 5 decode TP8; prefill-heavy workload (5,000 avg input, 500 output). PD curve "dominates across the entire interactivity spectrum." ## 5. Qualification: PD Is a Trade-off, Not a Magic Bullet **Speaker: Ashish** - **PD is favorable when:** long context with high ISL/OSL ratio, large models with rich model parallelism, middle concurrency regime, strict ITL streaming requirements, and availability of a **high-speed fabric (RDMA/RoCE)** for KV transfer. - **Stick with aggregated when:** short/moderate context, any model size, low concurrency, strict **TTFT** requirements (tunable in aggregated serving), or lack of a network fabric supporting KV transfers. ## 6. Key Takeaways (Ashish) - The design space is highly multi-dimensional; scheduler must evaluate SLO targets, QPS, KV cache locality metrics, PD ratios, and network topologies. - PD requires **dynamic PD ratio matching** evolving with autoscaling, independent scaling of PD pools, and continuous tuning of tensor/data parallelism. ## 7. GLM 5.2 Case Study (Ongoing) **Speaker: Yuchen** - Customers lack B200s and have H200s; goal is to make GLM 5.2 work well on H200 clusters. - Architecture ("wild path" in LLM-d): KV cache routing + PD disaggregation + parallelism strategies; **prefill pool up to 3 workers** optimized for throughput with DeepSeek-style approach; **decode = 1 dedicated worker** optimized for low latency; **NIXL** for KV transfer; per-worker LeaderWorkerSet with TP1, DP8, EP8. - Claimed benefit: modular — scale throughput by adding prefill workers without reconfiguring decode. - **Preliminary finding ("fun fact," discovered days before the talk):** BF16 KV cache is faster than FP8 KV cache for longer prefill on this setup. Presented as an ongoing exploration. - Results on agentic dataset (45:1 ISL/OSL ratio): with 2 prefill + 1 decode, **~4x faster TTFT and 60% more requests**. Explicitly flagged as **work in progress**; next steps include lowering TTFT and adding prefill replicas. ## 8. Closing Positions - **Yuchen:** agentic north-star work continues — session graph orchestration, preemption-aware scheduling, state reuse lifecycle, agentic benchmarks; contributions welcome in vLLM/AMD upstream and SIG groups. - **Ashish (final statement):** distributed inference "is not [a] challenge a single company can solve alone"; building in the open with CoreWeave, Google, IBM, NVIDIA, and other launch partners; invitation to contribute and visit the Red Hat booth. --- ## Contradictions & Qualifications Preserved - PD is explicitly **not a universal solution** — both speakers flagged failure modes (no fabric, low concurrency, strict TTFT cases). - GLM 5.2 results and the BF16-vs-FP8 KV cache finding are **tentative, ongoing work**, presented as preliminary. - Benchmarks are characterized as sanitized vs. chaotic reality — speakers acknowledge the gap rather than claiming their results fully close it. # Speaker Attribution Record — KV Cache-Aware Routing and P/D Disaggregation on Kubernetes ## Video - **Title:** KV Cache-Aware Routing and P/D Disaggregation on Kubernetes — Yuchen Fama & Ashish Kamra, Red Hat - **Format:** Conference session (inference/Kubernetes topic), ~20 minutes of talk content, includes an in-session demo video and closing music. ## Speakers ### 1. Ashish Kamra — **Co-presenter / Creator** - Self-introduced: **Senior Manager of Performance Engineering at Red Hat**. - Opened the session with welcome and agenda framing. - Delivered the section on **LLM Distributed (LLMD) framework overview** and **prefill/decode (P/D) disaggregation mechanics**, including: - Phase interference explanation (prefill = compute-heavy/bursty; decode = memory-bandwidth/latency-sensitive). - Step-by-step P/D request flow in LLMD (gateway router → endpoint picker → prefill worker → KV transfer metadata → decode worker). - Experimental results (P99 ITL aggregated ~900 ms vs. PD ~100 ms; concurrency-regime analysis; GPT-OSS 12B configs on H100s). - "When to use PD" decision matrix and key takeaways on multi-dimensional design space. - Handed off to Yuchen for the case study. ### 2. Yuchen Fama ("Yuch Chen" in transcript) — **Co-presenter / Creator** - Self-introduced: **Product Manager at Red Hat Inference**, working with **vLLM and AMD core maintainers**; also a contributor. - Delivered the section on **agentic-era inference characteristics** (multi-turn sessions up to ~3,000 turns, >90% cache hit rates, high input/output ratios, sub-agent patterns, context variance). - Delivered the **KV cache utilization/management** section (LLMD router endpoint-picker plugins, offloading tiers — NVMe SSD, file system XFS, Mooncake KV-centric store, session-aware eviction, session pinning). - Narrated the **KV cache-aware routing demo video** (first-turn ~3 s no cache hit; second-turn ~1 s cache reuse on same pod; third turn new system prompt ~3 s; fourth turn reuse ~1 s). - Delivered the **GLM 5.2 case study** (H200 clusters, 2P/1D configuration, NIXL for KV transfer, TP1 DP8 EP8, BF16 vs FP8 KV cache observation, ISL/OSL 45:1). - Closed the session with community/ecoystem call to action and booth mention. ### Audience/off-mic voice - One brief unintelligible interjection ("Stand here so you can look at it") during the demo segment — **unidentified speaker**. ## Referenced Sources & Third-Party Claims - **Anthropic API pricing:** cited by Yuchen for the ~10x cost difference between cached and non-cached tokens ("you also heard from earlier sessions"). - **Google and IBM:** cited by Yuchen as collaborators (with Red Hat) on a **trace replay tool in Inference Perf**; credits named individuals Ashoken and Jason for earlier sessions. - **SWE-bench and "watrices" traces from real-world cloud code sessions:** cited as example agentic workloads (transcript garbled; exact second name uncertain). - **Deep Learning.AI free course** on open-source inference by **Cedric and Andrew Ng** ("Andrew Ning" in transcript). - **Red Hat developer portal blog series** on distributed inference. - **CNCF:** LLMD described as hosted under the CNCF umbrella. - **Launch partners/ecosystem:** CoreWeave, Google, IBM, NVIDIA, "growing list" of adopters (as stated by Yuchen). - **GLM 5.2 benchmark numbers "on B200"** attributed to external/public claims ("You probably have seen tons of impressive numbers"), not the presenters' own measurements. ## Promotional Segments (Flagged) - Ashish's **Red Hat positioning block**: describing Red Hat as top contributor to vLLM/LLMD, incubating **GuideLLM, LLM Compressor, speculators**, the **Red Hat AI arc** model hub on Hugging Face. - Yuchen's **closing invitation**: join the SIG group, contribute to AMD upstream, visit the Red Hat booth downstairs. - The overall session functions partly as a **showcase of Red Hat's LLMD platform** (case study results described as "our own internal results at Red Hat"). ## Unavailability / Uncertainty Notes - **No curated metadata supplied**; speaker identities rest solely on transcript self-introductions (title lists "Yuchen Fama," transcript self-introduction renders "Yuch Chen" — same speaker, name spelling uncertain). - **Comment availability:** not indicated. - Demo video is embedded in the session; no external source link given for it. - Minor transcript garbling noted: "watrices" (workload trace name), "VM" likely = vLLM, "Euchin" = Yuchen, "LLMD" consistently used for the LListributed framework name. All right. Um, welcome everyone to yet another inference talk. I hope you have had a good conference so far. And u, so in this session, I mean I'm sure you people who have been in the room uh must have heard these terms many times by now. So we're going to do a little bit more deep dive into the challenges of LLM deployments for agentic workloads and uh in this session we'll focus specifically on KV cache away routing and uh PD disagregation um and also you know when you when you look at public inference uh benchmark results you are typically looking at very steady state isolated highly sanitized numbers and what those benchmarks actually don't show you u is the chaotic reality of multi-turn interactions, massive context fluctuations which are very typical of agentic workloads. So we'll also try to pull the curtain back on some of those complexities. Um by by way of introduction uh my name is Ashish Kamra. I'm a senior manager of performance engineering at Red Hat. And with me \>\> hi I'm Yuch Chen. I'm the product manager at Red Hat Inference working closely with VLM and AMD core maintainers. also a contributor myself. \>\> So here is the agenda for the next 20 minutes or so. Um Euchen will start with an analysis of inference behavior in the agentic era and some of the core characteristics and challenges. Uh next we next you will walk us through the KV cache um utilization and management strategies. I will break down the mechanics of pre-fill decode disagregation and walk you through some some results and then Euchen will again bring it all back together with our ongoing case study on our favorite open coding model GLM 5.2. Um and just a couple of uh sources from our side if you are more interested in learning more about open source inference we have a free course free course on deep learning.ai AI uh by Cedric and with Andrew Ning. Um and the other is a series of blogs on the Red Hat developer portal on distributed inference concepts uh troubleshooting and deployment patterns. Uh and for those who may not be aware since Red Hat is better known as the Linux company for enterprise Linux and uh the Kubernetes company for Open Shift uh but more recently we are also a major player in open source AI inference with uh us being the top contributor in VLM LLMD and the case of projects and also uh having incubated guide LLM for benchmarking LLM compressor for model quantization and speculators for uh speculative uh decoding models and we also bring it bring all of that together in a optimized model hub on hugging phase under the Red Hat AI arc. Um and we are also building the platform for the next wave of agentic inference workloads and with that I will hand over to you to uh walk you through more of it. So we are currently um at this inflection point moving from the era of classic inference to the agentic era. So when we look at the real world agentic work workloads such as uh sweet bench and also watrices from real world cloud code sessions they fundamentally break many assumptions we made with classic LM serving. uh as you heard actually many times in previous sessions for example multi-turns and new standard we found from a few turns all the way to 3,000 turns and also because agent frequently reuse the uh system prompt and the total definitions we usually see super high cash hit rate um oftentimes well exceeding 90%. Uh another thing is input output ratio is uh is massive oftentimes over a 100 ratio and even higher and in many cases and on top of that the context management is is incredibly complex due to this high variance because we can't just simply take the average and oftentimes we need to look at the distributions and the P90 numbers especially when you do uh capacity planning and also we observe really interesting patterns like sub Asian panel which is which further complex uh complicates scheduling. So to help communities study um this patterns we collaborate with Google thank you and also IBM our parent company to add uh a a trace replay tool in the inference perf you heard from earlier sessions u from Ashoken and Jason. Um so yeah feel free to check it out and the link is here. Uh next slide. Oh, so transition from the class uh the characteristics um we just saw for agentic workloads. We're no longer chasing this um this this raw throughput in a steady state. We often need to optimize uh for example interactive latency and they're very um highly volatile and client-driven context because user and you know client define the prompt structure. So this introduced several critical challenges. First of all, KV cache management becomes super volatile because the context is client determined as I said. So oftentimes we face this like you know frequent evictions and rewrites and secondly we also need to tune um the engine like VM with upper layer uh scheduling and routing. It needs that coordination such as prefix routing especially when latency becomes a primary uh scheduling matrix rather than like a secondary or afterthought. And thirdly, we also need to rethink our metrics. For example, we need to measure cats throughput separately. Why? Because on the right, it's really clear that economic stakes is very high. So, this is the uh anthropic API pricing. You also heard from earlier sessions. There's 10x cost difference between cash and non-cash tokens. So, 10x difference on your um token balance sheet is is pretty serious impact on your business. So next let's let's look at how the KV cache is um both utilized and managed in LMD. So LMD router has this really flexible um endpoint picker plugins we call the EP that can route the request to the optimal pods and that meet the KV cache locality and also the load criteria. So the EP continue probe each pods like VM pod matrix to score each pod on like the running for example running and waiting request and then the KV cache utilization also prefix uh cache availability and so we can schedule requests to the optimal pod with the lowest load and also highest possibility to um to of a cache hit. So um going down from to the KV cache management layer actually you also heard from earlier session right before this. So for agentic sessions when you have u hot warm and cold cache our current effort focus on for example um more offloading tiers like NVME SSD and also uh file system XF along with KV ccentric store um like uh moon cake and also implementing smarter and session a wire eviction policies such as priority and also session pinning to uh ensure this uh really important you know the the context persists exactly when and where it's needed. So, I'm gonna play this um video really quick. Uh it's a it's a short demo. \>\> Stand here so you can look at it. \>\> Okay. So, okay. So, this is a example of a KV cache bar routing. As you see, when we send the very first request and it populate the KV cache, it takes roughly 3 seconds. And when we actually look at where it's you know the KV cache uh is going there's no KV cache hit because it's the very first turn. And then when we have the second turn the request actually reuse a KV cache because as you see the system prompt is the same and this time takes about one seconds. And then when you actually look at the uh pod address exactly the same because we define the KV cache. Now going to the third turn a new request with different system prompt. Now it takes about three uh seconds and as you see you know right now and we don't find any KV cache here because you can tell it's different pod address and then if you just change the user prompt and keep the same system prompt and the next turn you you reuse the KB cache and in this in this time it takes roughly about uh one second. Yeah. So it's a pretty intuitive demo and um I'll turn it to Ashish to talk about the next side but before that what does problem does it solve? So often times the prefix routing KB cache routing helps you solve the TTFD problem and of course you'll improve your lat uh your your throughput but oftentimes for agentic workload is not just a TTFT your throughput is about your inter token latency how do we solve that so preview decode disagregation is a really uh powerful technique but there are times there work at times it doesn't work so I'll turn it to Ashish to give you a preview of um of the PD uh disregation So before we dive into PD, let's just uh look at what LLMD is. So LLMD is a high performance Kubernetes native and actually now works on non-cubernetes environments as well. Distributed LM LLM inference framework hosted under the CNCF umbrella. LLMD provides a unified intelligent control plane designed specifically for agentic era of inference workloads. Well, Euchin already talked about the router and the EP at the top of the slide. Um, the other aspects are workload APIs such as leader worker set and disagregated set that orchestrates complex multi- multi-node model execution and then autoscalers that monitors capacity bounds and real-time traffic mixes to independently scale up and scale down uh your pods depending on the system load. So now look now let's look at uh prefill decode disagregation in detail. Um uh okay so why does PD exist in the first place? So one of the most powerful patterns implemented by LLMD is prefill decode disagregation and you must have heard from some of the previous talks as well. So what happens is in in a nonPD situation in aggregated serving one pod is responsible for optimizing both your time to first token and your inter token latencies. Uh but in PD prefill and decode become independently scalable inference pods. But to understand why we actually need this we have to look at the physics of LLM execution. colloccating uh both prefill and decode tasks on the same GPU creates something called as phase interference. Prefill phase is the phase that creates the KV caches for your initial prompt. It wants high compute. It's highly bursty uh utilizes GPUs at uh high flops and and thrives on large batch parallelism to process the prompts and builds the initial KV cache. The decode phase on the other hand is generating one token at a time and it's more me memory bandwidth hungry. It's highly latency sensitive and requires high heavy cache residency. So in a in a in a traditional aggregated pod if you if there's a sudden influx of a long prefilled palm, it will completely stall the ongoing decode token generation process causing massive problems and jitter in user streaming latency. So, so how does PD actually work in practice in LMD? So, LNMD uses um uh you know like okay, we'll start with step one. A incoming request hits the gateway router which dynamically evaluates cluster states using something known as the endpoint picker you talked about and schedules the request to use PD disagregation selecting the optimal prefill and decode workers. The router then coordinates the transaction directly with the designated pre-fill worker. The pre-fill worker processes the prompt, construct the initial KV cache of the prompt and outputs the standard KV transfer metadata. Um, and the target decode worker actually pulls the computed KV caches um, uh, across the network fab fabric utilizing uh, the KV transfer metadata that the uh, uh, prefill pod had generated. Um okay so with that yes that's kind of how uh PD is implemented in practice in LMD and next I would like to show you some uh experimental results on where PD actually shines. So in this graph you can see that um uh in in in the standard aggregated deployment which is the top red line uh the P99 ITL uh hovers roughly around 900 milliseconds and you can you can see some fluctuations um up and down and but the the bottom blue line is the P99 uh inter token latency on a PD deployment and you can see that it's drastically almost nine times better at 100 millconds and it's also much smoother uh than the aggregated serving and uh this is some of our own internal results at Red Hat. So for a GPOSS 12B model uh 16 H100s uh the aggregated config is four replicas tensor parallelism 4 and the disagregated is two prefilled 2D code all with tensor parallelism 4. It's a highly multi-turn workload with a 10,000 token prefix and 128 tokens for every turn every turn. So, so this is a great chart like you can see at the bottom most line is a standard aggregated config that's uh is doing the default Kubernetes scheduling and uh and it's aggregated. So that's kind of our baseline and then the middle blue line is still aggregated but with the LLMD uh KV cache aware routing and you can almost see the gains just just based on the routing and the red line is actually the PD uh the pre-fill decode config with two pre-fill and two decode workers and you can actually see that like it's very similar to the aggregated config at the lower concurrency regimes and uh even and and very similar at the higher concurrency regimes but it's actually the middle part of the concurrency regime that PD actually shines and and these are some of the the classic parita curves that we see when you actually do PD and uh aggregated side by side. So these results are again from the GPTOSS 12B model 64 H100s aggregated is eight replicas TP8 and this a is uh three prefilled 5D code again TP8 and a pre-filled heavy workload with like 5,000 average input sequence length and 500 output sequence length and you can actually see the blue line is the the PD curve and the red line is the aggregated curve and the PD curve kind of dominates um uh the aggregate curve across the entire interactivity spectrum. Okay, but I don't want to leave you guys that PD is the answer to everything and it's a magic bullet. But um it's uh it's essentially a separation phase separation trade-off and not a magic bullet. So we created this uh matrix to help you decide when PD might be uh good for you. So if you're managing long context uh with high ISL OSL ratios and you if you have a large model that you're serving that can that you can apply rich model parallelism techniques um you're facing that middle concurrency regime uh that I I showed you in the previous graphs and and the very important part is that if you want uh strict ITL streaming requirements like you want the you want the token generation to be uh much more smooth um then you want to consider PD but we also saw that it requires transfer of KV caches from your pre-filled workers to your decode workers. So you must pro process an advanced uh high-sp speeded network fabric like uh RDMMA or rocky to support that KV cache transfer. And if you do not have such requirements, short moderate context, any model size, low concurrency regimes or uh if you have strict TTF requirements because you can actually tune them on an aggregate serving um and you the biggest point is like if you don't have the network fabric to support those KV cache transfers. So you might actually just want to stick with aggregated. So here is my key takeaway from all of this. So architecting this complex platform requires balancing a lot of u knobs and a highly multi-dimensional design space all of which is supported in LLMD. As you saw the scheduler must support or constantly evaluate SLO targets uh QEPs KV cache locality metrics PD ratios and network topologies to be able to route the request to the optimal FOD. While in while the PD design space you you need dynamic PD rate matching to adapt to PD ratios because you know you can start with a static PD ratio but it needs to evolve with the autoscaler as the traffic changes um and you need uh yeah autoscaling to scale PD pools independently um and constantly tweaking model parallelism techniques like tensor parallelism data parallelism uh to meet your SLOs's. So um I think with these uh I will hand it over to Euchen to anchor some of the concepts that we showed with the real world case study of serving the GLM 5.2 model uh which is uh still ongoing as we speak. \>\> Yeah, still ongoing. You probably have seen tons of uh impressive numbers of GLM 5.2 on B200 when we talk to our customers and they usually don't have you know the luxury of B200. They have a lot of H200. So we have to figure out how to like put all the knobs together and make GM 5.2 work really well for cluster of of H200. So uh we let's anchor all the concept together. Um we went through for example the uh KV cache routing PD disagregation. We kind of call them a wildl path in LMD and also we combine with different parallelism strategies to so we can uh independently uh scale prefuel paths because for agentic workload is super uh long you know like heavy prefill. So uh in this case we designed the prefuel pool using up to three workers optimized for uh high throughput uh with deep and then for decoup we use uh one dedicated worker and um that's optimized for for low latency. So we use Nixo for efficient KV transfer between the pools and also with the each worker we have the leader worker set group uh with TP1 DP8 and also uh EP8 uh expert parallelism 8. So the architecture is just highly modular because you can uh actually scale the throughput by simply adding uh preview workers without reconfiguring and um the decoup. So uh this highlights how AMD effectly effectively managed the complexity of combining like PB and DB and EPI scale. And also we found some interesting fun fact actually a couple days ago. Um B B B B B B B B B B B B B B B B B B B B B B B B B B B B B B B B B B B B B B B B Bf6 uh BF16 KV cache actually is faster than using like FPA uh KV cache for longer preview. Um this is also like we continue to explore and found like more interesting patterns, but more importantly uh we want to kind of just show the result really quick. So um for this uh data set agentic workload data set the ISO OSL ratio is pretty high 45 to1 ratio preview is uh is really the constraint you can tell um with 2P even 1D we have um 4x passer TDFT and also 60 uh% more requests and this is continuous like work in progress so the next step is we need to also put the upper layer lower TTFT and also adding more more preview replicas so um I know we're running out of time really quick. Uh we um the fundamental shift for agentic workload we're continuing to uh have this um uh agentic north uh northstar uh with session graph orchestration program award scheduling uh state reuse life cycle and also the uh agentic benchmark um we're working on. So you can find them uh in AMD upstream AMD and also you know feel free to join the SIG group and uh and contribute and um this is the very last slide. So distri distributed inference is not challenge uh every single comp a single company can solve along. We're proud to be uh building this uh future in the open alongside our incredible ecosystem collaborators uh core wave Google IBM Nvidia growing list of launch partners and industry adopters. So if you're passionate about the future of opensource inference, we invite you to join us. We do have a booth downstairs. Feel free to stop by, ask us any questions. And uh thank you so much for your time. \>\> \[music\]
